SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE
Pin-it

EREA 3 phase transformer Upri 230V ∆ - 400V Y+N // Usec 230V ∆ - 400V Y+N 16000VA (16KVA) SPT16000/BTE

Item No.: SPT16000/BTE
EREA

Delivery time: Please contact us for current delivery times

Enclosure

Trillingsdemper

€7.369,92 €5.158,94
(Price excluding VAT): €4.263,59
You Save: 30%

Of betaal in termijnen vanaf €171,96 p/m. Meer info

EAN
5414503099099
SKU
SPT16000/BTE

Technical specifications
Brand EREA
Commercial Order Number SPT16000/BTE
EAN 5414503099099
Class Three Phase Energy Efficient Low Inrush Current Protective Transformer (PVT)
Primary voltage 3 x 230 Vac ∆ -- 3x 400 Vac Y+N
Secondary voltage 3 x 230 Vac ∆ -- 3x 400 Vac Y+N
Rated power 16000VA (25KVA)
Degree of protection IP00
Efficiency  97,5%
Pcu (W) 313W
Po (W)102 W
Voltage drop (dU%) 1,82%
Dielectric strength to mass (Vac) 2500 Vac
Standards EN 61558-2-4
Maximum ambient temperatur ta (°C) 40 °C
Temperature Class B
Size A x B x C (mm) 480x220x415mm
Size D (mm) 320mm
Size E (mm) 190mm
Weight 110kg
Primary connection Screw terminals 10 mm;
Secondary connection Screw terminals 10 mm;
Φ (mm) 11 mm
Finish Vacuum and pressure impregnated

Options
On request Protection Class II
Degree of protection IP23, IP44 and IP65
Other voltages and other capacities
Zig-Zag switching groups
Connections with sockets and with power cords
With fuses
With electrostatic screens
Tropical Resistance Treatment
Option enclosure IP20 (accessoire) K20BTE/040
Option enclosure IP23 (accessoire) K23BTE/045
Option Damper (accessoire) SILENT BLOCK 50
