EREA 3 phase medical transformer 3x400V//230V 10kVA 230TMTHD10000

Name: EREA 3 phase medical transformer 3x400V//230V 10kVA 230TMTHD10000
Brand: EREA
SKU: 230TMTHD10000
Price: 3494.31 EUR
Availability: InStock

Item No.: 230TMTHD10000

Delivery time: Please contact us for current delivery times

Trillingsdemper

€4.991,87 €3.494,31

(Price excluding VAT): €2.887,86

You Save: 30%

Of betaal in termijnen vanaf €116,48 p/m. Meer info

EAN

5414503119933

SKU

230TMTHD10000

Technical specifications
Brand	EREA
Commercial Order Number	230TMTHD10000
EAN	5414503119933
Class	Energy Efficient Protection Transformer for Medical used Spaces
Primary voltage	3x 400 Vac Y+N
Secondary voltage	3x 230 Vac Y+N
Rated power	10000VA (10KVA)
Dielectric strength referred to frame (Vac)	2500 Vac
Dielectric strength to mass (Vac)	4500 Vac
Degree of protection	IP00
Standards	EN 61558-2-15 EN 60752
Maximum ambient temperatur ta (°C)	50 °C
Application	For medical used rooms
Protection class	Prepared for class I
Temperature Class	B
Voltage drop (dU%)	3%
Efficiency	96.9%
Pcu (W)	300 W
Po (W)	85 W
Size A x B x C (mm)	480x225x415mm
Size D (mm)	320mm
Size E (mm)	185mm
Weight	115kg
Primary connection	Screw terminals
Secondary connection	Screw terminals
Φ (mm)	11 mm
Finish	Vacuum and pressure varnish impregnated
