EREA 3 phase isolation transformer 230-400V//230V-400V 2,5kVA SPT2500/BTE/IP65

Name: EREA 3 phase isolation transformer 230-400V//230V-400V 2,5kVA SPT2500/BTE/IP65
Brand: EREA
SKU: SPT2500/BTE/IP65
Price: 2446.35 EUR

Item No.: SPT2500/BTE/IP65

Delivery time: Please contact us for current delivery times

€3.261,80 €2.446,35

(Price excluding VAT): €2.021,78

You Save: 25%

Of betaal in termijnen vanaf €81,55 p/m. Meer info

EAN

5414503121370

SKU

SPT2500/BTE/IP65

Technical specifications
Brand	EREA
Commercial Order Number	SPT2500/BTE/IP65
EAN	5414503121370
Class	Energy Efficient Protective Transformer (BTE)
Primary voltage	3x 230 Vac ∆ -- 3x 400 Vac Y+N
Secondary voltage	3x 230 Vac ∆ -- 3x 400 Vac Y+N
Rated power	2500VA (2.5KVA)
Degree of protection	IP65
Diëlektrische vastheid (Vac)	4500 Vac
Voltage drop (dU%)	4.7%
Dielectric strength to mass (Vac)	2500 Vac
Standards	EN 61558-2-4
Max. ambient temperature Ta (°C)	40 °C
Temperature Class	F
Application	For Industrial Applications
Efficiency	96.3%
Pcu (W)	108 W
Po (W)	44 W
Size A x B x C (mm)	409x234x328mm
Weight	43kg
Primary connection	Screw terminals 4 mm²
Secondary connection	Screw terminals 4 mm²
Finish	Vacuum and pressure impregnated
